125mm Wide Fully Enclosed Sliding Table Aluminum Linear Guide Motor Stage XYZ Axis Ball Screw Linear Actuator Module Slide Table(2Nm Motor Kit,50mm Stroke SFU1605)

125mm Wide Fully Enclosed Sliding Table Aluminum Linear Guide Motor Stage XYZ Axis Ball Screw Linear Actuator Module Slide Table1* Sliding table1* CouplingOr If you choosed a motor kit1* Sliding table1* Coupling1* 2Nm open loop stepper motorModule width: 125mmModule material:Industrial Aluminum ProfileEffective Stroke: 50MM-1950MM Total slide table length:Effective stroke +275mmGuide:2*HGR15 (15mm width)Block:4*HGH15CAMobile table size: 140mm*150mmMAX. Horizontal load: 120KG (50mm-1150mm stroke); 160KG (1250mm-1950mm stroke)MAX. Vertical load:60KGMotor bracket: Nema23/ Nema34 Stepper motor Or 60mm/80mm/90mm Servo motorRepeat positioning accuracy: 0.02mm-0.03mmBall screw accuracy:C7Ball screw material: Bearing SteelBall screw type: SFU1605 (50mm-1150mm stroke); SFU2005 (1250mm-1950mm stroke)Tips: 1. SFU1605 means screw diameter 16mm, pitch 5mm, the screw rotates once, the slide table moves 5mm;2. SFU2005 means screw diameter 20mm, pitch 5mm, the screw rotates once, the slide table moves 5mm;3. 50mm-1150mm stroke can be customized with SFU2005.

• Precision linear rails, ensuring smooth and stable movement. The advanced design allows for micron - level positioning, making it ideal for applications that demand utmost precision, such as 3D printing, microscopy, and semiconductor manufacturing.
• Robust Construction: Built with high - quality materials, this linear rail stage is durable and can withstand heavy loads. The anodized aluminum alloy body provides excellent corrosion resistance, while the hardened steel rails offer long - lasting performance. It is engineered to operate reliably in various industrial and laboratory environments.
• Easy Installation and Integration: Designed for hassle - free setup, our linear rail stage comes with a user - friendly installation guide and all necessary mounting hardware. It can be easily integrated into existing mechanical systems, saving you time and effort. Whether you're a DIY enthusiast or an industrial engineer, installation is a breeze.
• Versatile Applications: This linear rail stage is suitable for a wide range of applications. It can be used in CNC machines for precise cutting and milling, in robotic arms for accurate movement, and in automated inspection systems for reliable part handling. Its versatility makes it a valuable addition to any precision - based project.
• Excellent Customer Support: We are committed to providing top - notch customer service. If you have any questions or encounter any issues with our linear rail stage, our dedicated support team is always ready to assist you
